#MIKROTIK 10GBE SWITCH UPDATE#
#MIKROTIK 10GBE SWITCH PASSWORD#
#MIKROTIK 10GBE SWITCH MAC#

Four SFP+ cages, which accept both 1.25 Gb SFP and 10 Gb SFP+ modules.

Applies only when the device has booted RouterOS.

#MIKROTIK 10GBE SWITCH MAC#

In case the IP connection is not available, the Winbox tool ( ) can also be used to connect to the MAC address of the device. For recovery purposes, it is possible to reinstall the device from the network, see the CRS305-1G-4S+IN#Reset button. Winbox should be used to connect to the default IP address of 192.168.88.1 from any port, with the username admin and no password. The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility. We suggest starting here to get yourself accustomed to the possibilities. RouterOS includes many configuration options in addition to what is described in this document. From RouterOS: in the System, RouterBOARD menu, click "Settings" and there select "Boot OS".From SwOS: In the System menu, click the "Boot RouterOS" button on the bottom of the page.By default, the device will boot RouterOS, but you can reboot into SwOS in the following ways: The device supports booting RouterOS (for complete routing and switching configuration) or SwOS (for only using as a switch). Connect the power cord to the adapter, and then plug the power cord into a power outlet.Connect an Ethernet cable from your LAN to the LAN port of the POE adapter, please mind arrows for data and power flow.Connect the Ethernet cable from the device to the POE port of the POE adapter.When using 802.3af/at to power this device, we recommend not using grounding for best compatibility. The power consumption of this device under maximum load with fiber SFP modules is 10 W when using all RJ10 copper modules, up to 18 W. The first Ethernet port accepts passive or 802.3af/at Power over Ethernet in the range of DC ⎓ 12-57 V.Direct input power jacks DC1, DC2 (5.5 mm outside and 2 mm inside, female, pin positive) accept DC ⎓ 12-57 V DC.The device accepts powering from the two DC power jacks (redundancy fail-over) or from the first Ethernet port: We recommend using Cat5/6 shielded cable for our devices. This device is designed for use indoors by placing it on the flat surface or mounting on the wall when mounting on the wall, please ensure that cable feed is pointing downwards.

#MIKROTIK 10GBE SWITCH PASSWORD#

Set up your password to secure the device.

Open Winbox and upload them to the Files menu.

#MIKROTIK 10GBE SWITCH UPDATE#

To manually update the device go to our webpage and download the latest software version packages.

The device needs to have an active internet connection.

We recommend clicking the “Check for updates” button and updating your RouterOS software to the latest version to ensure the best performance and stability.

Use Winbox or Web browser to connect to the default IP address of 192.168.88.1 from any port, with the username admin and no password.

The Initial connection has to be done via the Ethernet cable, using the MikroTik Winbox utility or Web browser.

Connect the power adapter to the DC jack.

Place on the flat surface (see “Mounting”).

All ports bridged with IP 192.168.88.1/24 set on the bridge. The Default configuration, Switch mode all interfaces are switched LAN Configuration. The default configuration is Switch: *all interfaces switched LAN configuration. The device has four SFP+ cages (modules are not included) for high-performance 10GbE connectivity (1.25 Gbit modules are also supported) and a 1GbE copper port for management. This device is a 10 Gigabit SFP+ switch, powered by RouterOS.
